| Features |
|
♦ RoHS compliant design
♦ Two USB ports on the front panel
♦ Dual reset buttons for dual systems
♦ Two 8 cm cooling fans with replaceable fan filters
♦ Lockable door prevents unauthorized access |
|
|
 Specifications |
|
| Color |
W: White / B: Black |
| System Fan |
2 cm x 8 cm |
| Operating Temperature |
0℃ ~50℃ |
| Weight (Net/Gross) |
10.4 kg / 15kg |
| SBC Form Factor |
Full-size, slot CPU card |
| Drive Bays |
3 x 5.25″ + 1 x 3.5″ HDD
or 2 x 5.25″ + 2 x 3.5″ HDD
or 2 x 5.25″ + 1 x 3.5″ HDD + 1 x front accessible 3.5″
or 2 x 5.25″ + 2 x front accessible 3.5″ |
| I/O Ports |
2 x USB |
| Expansion Slots |
14 slots for RACK-305G
7 slots for RACK-305GATX |
| Indicators |
Power, HDD |
| Buttons |
1 x power switch, 2 x reset buttons |
| Construction |
Heavy duty metal |
| Dimensions (DxWxH) |
413mm x 431mm x 176mm |
| Operation Humidity |
10% ~ 90% |
|
|
|
 Ordering Information |
|
| Part No. |
Description |
| RACK-305G[C] -R22/ACE-935AL |
4U 14-Slot Rackmount Chassis, USB, (Black/ White), W/ACE-935AL-RS PSU (300W), RoHS |
| RACK-305G[C] -R22/A130B |
4U 14-slot rackmount chassis, (Black/White), 2 x 8 cm fan, with ACE-A130B-R10 (300W ATX model), RoHS |
| RACK-305G[C] ATX-R22/A130B |
4U ATX motherboard rackmount chassis, (Black/ White), 2 x 8 cm fan, with ACE-A130B-R10 (300W ATX model), RoHS |
|
|
|
|
|
|
